Your largest format. Our tightest quality control.
700mm round with soft back-glow only — the designer pick for ensuites. IP44, 5mm copper-free glass, back-lit halo LED. From Adelaide stock.
- Australian landed stock — no 6-week lead time
- Quality-checked in Australia before dispatch
- Two-stage QA: checked before departure and on arrival
VLM-04 — full technical data
All figures are production-verified. Contact us for third-party test reports.
| Dimensions & Weight | |
| Overall size | 700 × 700 × 35 mm |
| Glass thickness | 5 mm copper-free |
| Frame depth | 35 mm |
| Shipping weight | 9.8 kg / unit |
| Lighting | |
| CCT range | 2700 K — 6500 K (dimmable) |
| CRI | ≥90 Ra |
| Rated wattage | 30 W |
| LED lifespan | 50,000 hrs rated |
| Driver type | Constant current, flicker-free |
| Control & Safety | |
| Touch sensor | Capacitive — on/off + dim |
| Demister pad | Integrated, 220V 20W |
| IP rating | IP44 — splash proof |
| Safety film | Shatter-retention backing |
| Power cord | AU 3-pin plug, 1.2 m |
| Materials & Finish | |
| Glass | 5 mm copper-free float glass |
| Frame | Brushed black aluminium · Brushed gold aluminium |
| Halo detail | Sandblasted frosted ring, acrylic diffuser |
| Backing | Safety film + moisture seal |
| Compliance | |
| Certification | SAA / RCM — Australian market |
| Warranty | 24 months from invoice date |
| MOQ | No fixed minimum for approved trade accounts |
VLM-04 technical drawing · front, back and side views · click to enlarge
Built for builders who can’t afford a callback.
Quality assured in Australia
Every unit is inspected and quality-verified on arrival at our Adelaide warehouse, before it goes anywhere near your site. A callback costs your crew more than any saving on a cheaper mirror.
AU stock, ready now
Held in Adelaide. No 6-week lead time. Order Monday, ship Tuesday. The largest format — available immediately when your project moves.
Two-stage quality assurance
Every shipment quality-checked before departure and again on arrival in Australia. No blind shipments.
What’s inside the frame matters.
The VLM-04 is the large-format round — same copper-free glass, same sandblasted halo, same AU stock pool. Just more of it.
5mm copper-free float glass
No edge corrosion in humid bathroom environments. Specified for projects with long structural warranties.
Full-ring sandblasted halo
700mm format carries a full, wide halo ring. Sandblasted into glass, not film. Acrylic diffuser eliminates hot spots across the full perimeter.
Brushed aluminium frame
Extruded aluminium in brushed black or brushed gold. Both available from AU stock. Shadow-gap wall reveal finish.
Shatter-retention safety film
Rear film holds fragments on impact — important for a mirror that’s a statement piece in a feature bathroom.
The VLM-04 in context
Get pricing and lead time for the VLM-04.
Send us your project spec and volume. We’ll come back within one business day with pricing, stock levels, and delivery timeline.
